Vertical packaging machine is a very wide range of packaging equipment, which can be used with different equipment to achieve packaging of different products. For example, when used with a multi-head weigher, it can be used for weighing and packaging granular products. Used together with auger filler, it can be used for packaging of powder products.
The vertical packaging machine is fed by the film stretching and feeding device during the packaging process. The film passes through the film cylinder to form a cylindrical shape, and the side is heat-sealed by the heat longitudinal sealing device. The photoelectric detection device cuts the length and position of the bag.
1. The vertical packaging machine adopts dual servo control system, which can choose servo single film/double film structure according to material characteristics and packaging materials, and vacuum adsorption film system is optional.
2. Horizontal sealing servo control system can realize automatic setting and adjustment of horizontal sealing pressure and horizontal sealing opening stroke.
3. The automatic deviation correction system makes the tracking and positioning more accurate and convenient, and adapts to different customer needs.
4. Various packaging forms: pillow bag, ironing edge bag, gusset bag, triangle bag, perforated bag, multi-pack, etc.
5. The vertical packing machine can cooperate with computerized multi-head combination scales, screw scales, electronic scales, measuring cup systems and other measuring equipment to achieve accurate packaging.
Powder: seasoning powder, coffee powder, milk powder, medicine, health care products, etc.
Particles: nuts, sugar, grains, tea, dried vegetables and fruit, etc.
Model | CK-LK720 | CK-LK520 | CK-LK420 |
Film width | max 720mm | max 520mm | max 420mm |
Bag width | 110-350mm | 90-250mm | 80-200mm |
Bag length | 100-420mm | 80-350mm | 50-300mm |
Packing speed | 10-50bags/min | 10-70bags/min | 15-80bags/min |
Packing range | 150-4000ml | 150-2000ml | 150-1500ml |
Film thickness | 0.04-0.10mm | 0.04-0.10mm | 0.04-0.10mm |
Power | 4kw/220v 50-60Hz | 3kw/220v 50-60Hz | 2.5kw/220v 50-60Hz |
Machine size | 1780*1350*2000mm | 1430*1200*1700mm | 1400*970*1700mm |
Machine weight | 800kg | 650kg | 450kg |
Air consumption | 0.8m³/min 0.8mpa | 0.4m³/min 0.6mpa | 0.4m³/min 0.6mpa |
Packing Material | bopp/cpp, bopp/vmcpp, bopp/pe, pet/vmpet/pe, ny/pe, pet/pet |
